Fan Assembly, Card Cage
331
Fan Assembly, Card Cage
Removal
1. Prepare the printer for maintenance (page 313).
2. Cabinet Model: Remove the paper guide assembly (page 348).
Pedestal Model: Remove the top cover assembly (page 327).
3. Disconnect the fan cable connector:
Cabinet Model, Figure 46, page 416.
Pedestal Model, Figure 41, page 404.
4. Cabinet Model: Remove the two fan mounting screws from the bottom of the fan. (See Figure 46, page 416, item 2.)
Pedestal Model: Remove the four fan mounting screws and nuts. (See Figure 41, page 404, items 1 through 4.)
5. Remove the card cage fan assembly from the card cage.
6. Remove the shield between the card cage fan and bracket.
Installation
ATTENTION
Install the fan so the label faces toward the inside of the printer. Air flow is INTO the card cage.
1. Reverse steps 2 through 6 of the removal procedure.
2. Return the printer to normal operation (page 314).
