Coil Temperature Adjustment
383
Coil Temperature Adjustment
This procedure applies only to models 6500-v15 and 6500-v20.
Do this procedure if the printer’s original controller board, power supply board, or shuttle frame assembly have been replaced.
Do not do this procedure if the controller board, power supply board,or shuttle frame assembly were removed and reinstalled as
part of other maintenance tasks.
IMPORTANT
The shuttle frame assembly must be at room temperature to do this procedure. Power off the printer and let it cool for
at least one hour before doing this procedure.
1. Raise the printer cover.
2. Power on the printer.
3. If the printer is in the READY state, press the STOP key. The printer must be in the NOT READY state to do this procedure.
4. Press MENU + CONFIG + SCROLL ↑ + SCROLL ↓. (Press all four keys at the same time.)
“SERVICE / PRINTER MECHANISM TESTS” appears on the display.
5. Press RETURN + ENTER to unlock the ENTER key.
6. Press the SCROLL ↑ or SCROLL ↓ key until “SERVICE / SET COIL TEMPERATURE” appears on the display.
7. Press ENTER. The display tells you to “PLEASE WAIT” while the coil temperature is set by an automatic calibration
sequence in printer software.
8. When the display again reads “SERVICE / SET COIL TEMPERATURE” press RETURN + ENTER to lock the ENTER key.
9. Press STOP to exit the menu and put the printer in the NOT READY state.
- OR -
10. Press START to exit the menu and put the printer in the READY state.
11. Coil temperature is now set. Power off the printer and close the printer cover.
