280
IBM Coax/Twinax Expansion Board for PSA3 Controllers
1
J2
2
3
4
5
6
7
8
9
10
Twinax Connection
TWINAX PHASE A
11
12
13
14
15
16
17
TWINAX PHASE B
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
µ
.01
10%
500V
F
1
J3
2
Coax Connection
COAX DATA
COAX SHIELD
9400 pF, 1500 V Built-in
capacitor coax shield to
frame ground
