Customer Engineer (CE) Tests
A set of printer tests is included in the configuration menu structure for use as maintenance tools. These are called “Customer
Engineer Tests” (CE Tests) because they are for your use; they are not available to the user through his documentation. You
will use these tests in various troubleshooting and adjustment procedures. CE tests do not run at the rated speed of the printer.
Figure 7. This figure shows the menu structure of the Customer Engineer Tests.
CE Tests
SERVICE
PRINTER MECHANISM TESTS
SERVICE
HAMMER PHASE VALUE
SERVICE
END OF FORMS ADJUST VAL
SERVICE
IPDS DEMOS
Burn In Test
Plot Test
Shuttle Only
Shuttle Slow
Shuttle Fast
Hammer Phasing
End of Forms Adjust
1 -1000
NOTE: Value is a numeric
unit only. This test is
defined on page 218.
Procedure on page 381.
4 - 76, 40 DOTS*
Unit of dot measurement
is dot rows. Procedure on
page 378.
Slot 1
... to ...
Slot 8
in increments of 1, then
Start Demo
(On printers using IPDS
emulation.)
SERVICE
MEMORIZE IPDS DEMO
SERVICE
SELECT CT TYPE
SERVICE *
SET COIL TEMPERATURE
DISABLE*
ENABLE
(On printers using
IPDS emulation.)
NOTE: * = Default Value
* 6500-v15 and -v20
printers only.
(Procedure on page 383.)
SERVICE
PRINTER MGMT
SERVICE
ENERGY SAVER TIMER
ENABLE*
DISABLE
Demo Count
1 *
2
5
10
Continuous
SERVICE
DEMO COUNT
PRINTER MGMT
Serial
PRINTER MGMT
Debug Port Cfg
PRINTER MGMT
Clear Password
PRINTER MGMT
Reboot w/Factory
Done
ENTER
Printer reboots
with Factory
configuration.
ENTER
Go to next page
Go to next page
A
B
NOTE:
ENTER key to move down
SCROLL ↑ to move to next item
STANDARD*
SIMPLE PROTOCOL
(On printers with CT
installed)
ENTER
SERVICE
C/T DATA TIMEOUT
3 to 9 seconds
in 1 second
increments
(On printers with CT
installed)
PRINTER MGMT
MANAGER PORT NO.
PRINTER MGMT
PORT TIMEOUT
SERVICE
UPGRADE NETWORK ADAPTER
ENTER
Printer reads and
upgrades adapter
settings.
(On printers with external
NIC adapter.)
3001*
Range: 1023 to
65535 in increments
of 1
100 SECONDS *
Range: 1 to 255
seconds in
increments of 1
PRINTER MGMT
DEBUG ACCESS
ENABLE *
NO TELNET DEBUG
PRINTER MGMT
ADAPT TO DEFAULT
ENTER
PRINTER MGMT
E-NET TO DEFAULT
ENTER
(On printers with
external NIC
adapter.)
(On printers with
PCI NIC.)
To Next Page
