Figure 7 (continued). This figure shows the menu structure of the Customer Engineer Tests.
From previous
page
PRINTER MANAGEMENT
Serial
Serial
Select Port
Select Port
Debug *
Host
Serial
Baud Rate
Baud Rate
9600 BAUD *
19200 BAUD
38400 BAUD
57600 BAUD
115200 BAUD
2400 BAUD
4800 BAUD
Serial
Word Length
Word Length
8 *
7
Serial
Stop Bits
Stop Bits
1 *
2
Serial
Parity
Parity
None *
Odd
Even
Serial
Modem
Modem
Disable *
Enable
Serial
Modem NVM
Modem NVM
Enable *
Disable
Serial
Modem Status
Modem Status
Enable *
Disable
Serial
Dial Method
Dial Method
Tone *
Pulse
From previous
page
Debug Port Cfg
Baud Rate
Baud Rate
9600 BAUD *
19200 BAUD
38400 BAUD
57600 BAUD
115200 BAUD
2400 BAUD
4800 BAUD
Debug Port Cfg
Word Length
Word Length
8 *
7
Debug Port Cfg
Stop Bits
Stop Bits
1 *
2
Debug Port Cfg
Parity
Parity
None *
Odd
Even
B
NOTE:
ENTER key to move down
SCROLL ↑ to move to next item
Diagnostic Port
Ethernet
(If installed)
A
