IBM Infoprint 6500-v05 User Manual

269
PSA3 Controller
CAUTION: Do not try to remove or replace
the NVRAM. The NVRAM contains a
lithium battery that can explode if replaced
incorrectly. NVRAM is replaced only at the
factory.
1
J106
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
PLAT 1
Motor Sensor Left
RIB L1
PLAT 2
RIB L2
PLAT 3
RIB L3
PLAT 4
RIB L4
CC FAN +
L RBN POST +
CC FAN -
L RBN POST -
POD A
PMD A
POD K
PMD K
POD C
PMD C
POD E
PMD E
+48V
µ
.01
10%
100V
F
1
J101
2
3
4
5
6
7
8
9
10
Power Supply
470 PF
10%
50V
11
12
470 PF
10%
50V
+8.5V
+48V
VCC1
N TEMP HI
N STDBY
100 PF
10%
50V
µ
.01
10%
100V
F
µ
10
10%
16V TANT
F
1
J107
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
PF 1
Motor Sensor Right
RIB R1
PF 2
RIB R2
PF 3
RIB R3
PF 4
RIB R4
EXH FAN -
BANK FAN
PLAT OPEN SW
R RBN POST +
PLAT OPEN RET
MPU -
COVER OPEN SW
MPU +
+48V
µ
.01
10%
100V
F
EXH FAN +
R RBN POST -
COVER OPEN RET
