PSA3 Controller (continued)
1
J105
2
3
4
5
6
7
8
9
10
PH1
Hammer Bank Power
PH2
PH3
PH4
LDFB
1
J108
2
3
4
5
6
7
8
9
10
HMR DAT
Hammer Bank Logic
HMR DAT RET
HMR CLK RET
CMD DAT RET
DMD CLK RET
HMR CLK
CMD DAT
CMD CLK
COIL
50 MHz
+10V SW
µ
.01
10%
50V
F
COIL
50 MHz
1
J120
2
3
4
5
6
7
8
9
10
C167 DB TXD
EC Diagnostics
PPR TRIG
FT EVENT
SHUT DIR
NC
C167 DB RXD
PPR MOVING
MPU OUT
VCC
10K
1%
0.1W
3300 PF
5%
100V
3300 PF
5%
100V
3300 PF
5%
100V
3300 PF
5%
100V
EC BOOT STRAP
0 Ohm
0.125W
