311
5 Removals and Adjustments
About This Chapter
This chapter contains removal, installation, and adjustment procedures for the parts and assemblies that you can replace at the
field service level of maintenance.
Removal and installation procedures are combined. These procedures begin on page 315.
Adjustment procedures begin on page 368.
Part numbers for replacement parts are listed in the Parts Catalog, which begins on page 390.
Tools And Materials
You need the following tools and materials to service the printer:
Item Part No.
IBM Line Matrix Printer Configuration Utility Disk 63H7379
1-30 Inch-pound Torque Screwdriver 16F1661
ESD Wrist Strap 6405959
Feeler Gauge, Flat, 0.010 inch
Feeler Gauge, Flat, 0 .011 inch
Feeler Gauge, Flat, 0 .012 inch
Feeler Gauge, Flat, 0 .013 inch
Feeler Gauge, Flat, 0 .040 inch
Force Gauge, 20 lb. 25F9687
