299
Cable Assembly, Ribbon Guide
Pin Connection
P106 (LRP) / P107 (RRP) Wire Color
Pin 1 Black
Pin 2 Black
Left Guide = P106 / LRP
Right Guide = P107 / RRP
39U2539 — Left
39U2540 — Right
Pin 1
Pin 2
