Resistors, Terminating
356
Figure 22. This figure shows the size and location of the terminating resistors on the controller board.
Resistor Kit: 14H5525
Default: 470 Ohm
Alt 1: 220 Ohm
Alt 2: 1K Ohm
Default: 1K Ohm
Alt 1: 330 Ohm
Alt 2: None
RP1
RP2
Controller Board
