Platen Stop Assembly
354
Platen Stop Assembly
NOTE: The forms thickness lever is part of the platen stop assembly.
Removal
1. Prepare the printer for maintenance (page 313).
2. Loosen—do not remove—the 7/64 inch clamp screw and pull the platen stop assembly off the platen shaft. (See page 413,
Figure 45, items 12 through15.)
Installation
1. Install the platen stop assembly on the right hand platen shaft, pressing the interlock switch out of the way as the lever
slides past it. Tighten the 7/64 inch clamp screw. (See Figure 45, page 413.) Open and close the forms thickness lever to
make sure the clamp screw does not touch the right ribbon guide.
2. Return the printer to normal operation (page 314).
