259
Figure 12. Connecting the Power Supply Tester
Connector P101
Controller Board
Connector J101
Power Supply Tester Load
Block — Can become warm
when used continuously
Power Supply Board
Stacker Power Cable
(Only on cabinet
models with the
power stacker)
Pin 1
Pin 1
Pin 1
