IBM Infoprint 6500-v05 User Manual

Memory Modules and Security Key
341
Figure 18. This figure shows the locations of Memory Modules and Security Key on the PSA3 controller board.
Data Stream LP+
IGP
LP+
ANSI
LP+
PGL
ANSI
LP+
VGL
ANSI
LP+
CT
LP+
CT
PGL
LP+
CT
VGL
LP+
IPDS
CT
LP+
IPDS
CT
PGL
LP+
IPDS
CT
VGL
LP+
Flash 8 MB 8 MB 8 MB 8 MB 8MB 8 MB 8 MB 8 MB 8 MB 8 MB 8 MB
SDRAM
(Permanent
Installation)
32
MB
32
MB
32
MB
32
MB
32
MB
32
MB
32
MB
32
MB
32
MB
32
MB
32
MB
CT Installed No No No No No Yes Yes Yes Yes Yes Yes
Memory Requirements for Emulation Options
J11: 72-pin Flash Memory SIMM:
8 MB = P/N 75P2810
16MB = P/N 10R4054
(NOTE: J10 is not used)
IMPORTANT:
The controller board does not
support EDO RAM.
PSA3 Controller Board
Notched End
on this side
Flash Memory:
J9: Security Key
V5
SDRAM soldered to controller board
