Motor Assembly, Paper Feed
343
Installation
1. Position the paper feed motor assembly on the right side plate and install the motor mount bolts and nuts finger tight (page
416, Figure 46).
2. Connect the paper feed motor cable connector to connector P107, then connect P107 to J107 on the controller board. (See
page 323.)
3. Model 6500-v20 only: install the heat sink to the base of the paper feed motor so that the heat sink is flush with the top
edge of the motor and protrudes down toward the card cage. Torque the heat sink mounting screws to 18 inch-pounds
(2.03 N•m).
4. Work the paper feed timing belt onto the paper feed motor pulley and the splined shaft pulley.
5. Using the straight end of a force gauge, apply 15 pounds (66.7 N) of pressure to the paper feed drive motor near the
mounting base of the motor. Use the splined shaft to steady the gauge.
6. Reduce tension to 12 pounds (53.4 N) and torque the motor mount bolts to 18 ± 2 inch-pounds (2.03 ±
0.23 N•m). Use the
1-30 inch-pound Torque Screwdriver, IBM part number 16F1661.
NOTE: Belt tension is correct if the belt deflects 1/8 inch midway between the pulleys.
7. Snap the timing belt cover into the slots in the side plate.
8. Cabinet Model: Install the paper guide assembly (page 348).
Pedestal Model: Install the top cover assembly (page 327).
9. Return the printer to normal operation (page 314).
