Belt, Platen Open, Adjustment (Figure 25)
372
Legend:
1) Belt Cover
2) Motor Mount Screw (2)
3) Platen Open Motor Shaft
Figure 25. This figure shows how to adjust the platen open belt.
A
1
3
2
3/16 inch
A
