Mechanical Controls: Figure 6
38
Figure 6. This figure shows the locations of the mechanical controls on on floor cabinet and pedestal model printers.
Paper
Supports
Tractor Lock
Left Tractor
Right Tractor
Vertical
Position
Knob
Forms
Thickness
Lever and
Scale
Tractor Lock
Ribbon Loading
Path Diagram
Platen Stop
