Chapter 6 Illustrated Parts Breakdown
393
(Figure 35)
Item
No.
Part No. Description Notes
1 39U2474 Cover, Common Top, Cab (Black) Includes mounting hardware
2 57G1492 Window, Top Cover Not visible in Figure 35
3 39U2512 Wireform Paper Guide Assembly
4 39U2475
39U3010
39U2489
Front Door Assy, Stealth Black
Rear Door Assy, Stealth Black (no power stacker)
Rear Door Kit (with power stacker)
Includes item 14
5 39U2475 Door Kit, F/R Cab (Black) Includes item 14
6 57G1485 Caster, with Brake Two at front
7 57G1486 Caster, without Brake Two at rear
8 39U2477 Logo, IBM Infoprint 6500
9 30H4008 Wire Rope, Front and Rear One on each door (Rear not shown in
Figure 35)
10 30H3986
24H8963
Re-Ship Kit, Cabinet Model, without power stacker
Re-Ship Kit, Cabinet Model, with power stacker
Not shown in Figure 35
Not shown in Figure 35
11 14H5572 Hardware Kit Not shown in Figure 35. Contains all
of the SAE fasteners used in the
printer.
12 63H7510 Door Seal Kit
13 63H7398
30H4010
Top Cover Seal Kit
Magnetic Seal
Foam only, three pieces
Foam with magnet, one piece
14 93F7037 Door Hinge, Top Included in items 4 and 5
15 57G1484 Door Hinge, Bottom
To Next Page
