Chapter 6 Illustrated Parts Breakdown
397
(Figure 37)
Item
No.
Part No. Description Notes
1 39U2478 Operator Panel, Cabinet Includes mounting hardware
2 10R4007
10R4008
10R4009
10R4010
10R4011
10R4012
10R4013
10R4014
Operator Panel Overlay, English
Operator Panel Overlay, French
Operator Panel Overlay, German
Operator Panel Overlay, Spanish
Operator Panel Overlay, Italian
Operator Panel Overlay, Dutch
Operator Panel Overlay, Brazilian Portuguese
Operator Panel Overlay, Polish
3 Ref Screw, Hex w/Lock Washer (2) 6-32x.375
4 14H5300 Cable Assy, Operator Panel
5 57G1481 Dashpot Kit Includes ball studs, spring clips, and
mounting hardware
6 Ref Screw w/Lock Washer (3) 6-32x.375
7 Ref Screw w/Lock Washer (2) 6-32x.175
8 57G1440 Fan Assembly
9 Ref Duct, Air Exhaust
10 10R4630 Paper Entrance Guide Model v20
11 10R4631 Spring, Paper Entrance Guide (2) Model v20
12 10R4632
10R4633
Bracket, Paper Entrance Guide, Right
Bracket, Paper Entrance Guide, Left
Model v20
Model v20
To Next Page
