Chapter 6 Illustrated Parts Breakdown
399
(Figure 38)
Item
No.
Part No. Description Notes
1 39U2479 operator panel Assembly, Ped, V3
2 Ref Screw, Captive (2)
3 39U2482 Lid Assembly, Pedestal
4 Ref Screw (2)
5 14H5300 Cable Assembly, operator panel
6 39U2480 Pedestal Kit, Grey
7 39U2481 Field Kit, Caster Kit, Ped
8 39U2507 Window, Top Cover
9 39U2482 Housing, Pedestal, V3
10 Ref Screw (4) 10-32x.625
11 63H5118 Paper Tray
12 28P0595 Paper Fence, Rear, Ped
13 39U2541 Rear Acoustic Shroud Optional feature
14 39U2520 Panel, Lid, Quick Access
15 39U2519 Panel, Quick Access, Ped
16 39U2504 Re-Ship Kit, Pedestal Not shown in Figure 38
17 24H8533 Paper Tray, Front, Ped
18 39U2532 Static Brush, Pedestal
19 39U2531 Top Cover, Pedestal, Base Assembly
