Chapter 6 Illustrated Parts Breakdown
401
(Figure 39)
Item
No.
Part No. Description Notes
1 39U2542 Shuttle Cover Assembly Air Shroud Assembly. Includes items
2 and 11.
2 Ref Screw, Captive (2) 10-24x.62 with O-ring, .125x.250x.06
3 Ref Screw, Thread Forming (4) 6-32x.25
4 Ref Barrier Shield
5 57P1746 Paper Path, V3 All cabinet models
6 Ref Screw, w/Lock Washer (3) 6-32x.25 and #6 Flat Washer
7 54P1379 Platen/Paper Feed Cover Kit Paper feed belt cover shown in Figure
39. Platen open belt cover: item 24,
page 413.
8 57G1468 Belt, Timing, 050P, 100 Teeth Paper Feed Belt
9 08H7954 Anti-Static Brush Kit Mounts to top of item 4
10 Ref Power Supply Insulator Taped to card cage along upper edge
11 14H5179 Paper Scale
