Chapter 6 Illustrated Parts Breakdown
417
(Figure 46)
Item
No.
Part No. Description Notes
1 57G1440 Fan Assembly Air flow is into card cage
2 Ref Screw, w/Lock Washer (3) Two 6-32x1.75 on botton
One 6-32x0.50 on top left
3 14H5281
02N7169
Paper Detector Switch Assy
Paper Detector Switch Assy
Standard switch
Black Back forms
4 Ref Screw, Thread Forming, 6-32x.375 (2)
5a
5b
10R4779
10R3342
Paper Feed Motor Assy, All Except Model v20
Paper Feed Motor Assy, Model v20 Model v20 only: Re-use the original
heat sink. Install it on the motor base
and torque the mounting screws to
18 inch-pounds (2.03 N•m).
6 Ref Motor Pulley, Platen Open, Driver Part of item 9
7 Ref Screw, Hex w/Lock Washer (2) 10-32x.50
8 39U2540
39U2539
Ribbon Guide Cable Assembly, RH
Ribbon Guide Cable Assembly, LH
9 54P1453 Platen Open Motor Assembly Includes item 6
10 Ref Washer, Flat #4 (2)
11 Ref Screw, Hex w/Lock Washer (2) 4-40x.38
12 Ref Screw, Hex w/Lock Washer (2) 10-32x.50
13 Ref Shield, Card Cage Fan
14 39U2534 Ribbon Motor Assembly, w/Hub Includes ribbon hub
15 Ref Screw, Hex w/Lock Washer (2) 6-32x.50
16 Ref Washer, Flat #6 (2)
