List of Illustrations
496
(Figure 92)
Item No. Part No. Description Notes
2 Ref Washer, 5/16 X .200 X .030, Stainless Steel
3 Ref Screw, Hex Skt Btn Hd, Zinc M3X8mm
4 Ref Washer, Shim, .125 ID X .010 inch Thick
5 Ref Timing Belt Tensioner Assy, Pwr Stkr
6 39U2535 Paper Deflector (Black)
7 Ref Clip-On Bearing Part of item 36
8 Ref Screw, Torx, 6-32 x .25 Part of item 36
9 Ref Screw, Shoulder, 10-32 Part of item 36
10 24H8968 Timing Belt
11 39U2511 Shaft, Lift
12 17R7812 Pulley, Timing, Fairloc,12T
14 10R2841 Clip, Ground, Dimpled, Pwr Stkr Part of item 47, but can be ordered
separately
15
16
24H8969
54P1469
Motor Assembly, Power Stacker
Motor, Stepper, Power Stacker
Elevator motor (Figure 92)
Paddle motor (Figure 93)
Paper puller motor (Figure 93)
20 24H8970 Constant Force Spring
21 39U2545 Field Kit, Tray, Cab, Rear, Black
22 75P1182 Slide, Ball Bearing, Rear Tray
23 75P1183 Tent, Paper, Stacker
25 24H8971 Chain Mount chains outboard of shafts
30 Ref Nylon Plug
