List of Illustrations
503
(Figure 95)
Item
No.
Part No. Description Notes
36 24H9004 Stacker Hardware Kit Kit not illustrated
97 24H9000 Holder, LED, Flat
105 24H8990 Photodarlington, NPN, Rectifier
106 Ref Retaining Ring, External, 0.093 inch Part of item 115
107 Ref Screw, Panhead, Type B, 2 x 3/16 Part of item 36
108 Ref Shaft, Paper Detector Switch, Long Part of item 115
110 Ref LED, IR, Rectangular
115 02N8327 Field Kit, Power Stacker, PMD Paper Motion Detector
116 Ref Spring, Torsion Part of item 115
To Next Page
