Index
542
Spare parts and part numbers, 390
Specifications
cables, 511
interfaces, 511
labels, 508
paper, 507
printer, 504
ribbon, 505
temperature, 509
Splined shaft
replacement, 359
Spring
extension, hammer bank, replacement, 364
SPX, 250
SPX FOUND, ERROR: KEY NOT DETECTED, 168
SPX NOT NEEDED OPTIONS ENABLED, 169
Stacker, power, 451
confidence check, 460
how to operate the stacker, 453
illustrated parts breakdown, 494
installation, 473
loading and starting, 457
motor check, 461
operational inspection, 459
operator panel, 454
problems, 459
removal, 465
replacing
constant force spring, 485
timing belts, 487
Start of call, 40
Start up sequence, 229
Status LEDs on the controller board, 229
Support shaft
replacement, 361
Switch
paper detector switch assembly, replacement, 365
platen interlock switch assembly, replacement, 366
power, replacement, 322
T
Temperature specifications, 509
Temperature, coil, adjustment, 383
Tension adjustment
dynamic paper tension, 384
paper feed timing belt, 369
platen open belt, 371
Terminating resistors
location of, 356
replacement, 355
TESTING HARDWARE - PLEASE WAIT, 169
Tests
boot diagnostics menu, 221
cable shorts, 254
customer engineer (CE), 216
hammer bank cable shorts, 253
main wire harness diagnostic, 256
power supply operation, 258
print, operator, 213
printer information menu, 226
shuttle electrical shorts, 252
Time
To Next Page
