584 IBM Flex System V7000 Storage Node Introduction and Implementation Guide
13.3 Monitoring system status and health
In this section, we describe the procedure to monitor the system status and the health.
13.3.1 Using FSM for status and health
IBM Flex System Manager provides a set of tools that you can use to monitor and manage
the status and health of resources in your environment from a single interface.
The navigation area provides links to tasks and task categories such as Resource Explorer,
Availability, Inventory, System status, and Health Summary.
Figure 13-4 shows you how to open the navigation area. Click the tab with the arrow icon on
the left side of the pane.
Figure 13-4 FSM - tasks management and navigation (1 of 2)
Tip: The Chassis Manager view in the management software web interface is the primary
interface for selecting managed resources and performing management tasks on those
resources. However, some of the procedures in this section include steps that instruct you
to use the navigation area, which is hidden by default in the web interface
Click this tab to view a Task List

IBM V7000 Specifications

General

Model	IBM Storwize V7000
Storage Type	Hybrid Flash Array
Maximum Capacity	1.2PB
RAID Levels	0, 1, 5, 6, 10
Connectivity	8 Gbps Fibre Channel, 16 Gbps Fibre Channel, 1 Gbps iSCSI, 10 Gbps iSCSI
Management	Command-line interface (CLI), Graphical user interface (GUI)
Form Factor	2U
Drive Bays	12
Maximum Raw Capacity	1.2PB
Operating System Support	AIX, HP-UX, Linux, VMware, Windows
Data Reduction Features	Real-time Compression, Deduplication
Drive Types	SSD, HDD
Scalability	Scale-up (drive enclosures) and scale-out (clustering) capabilities
