WindO/I-NV4 User’s Manual 2-69
5 WindO/I-NV4 Common Operations and Settings
2
WindO/I-NV4 Features & Basic Operations
■ Bit Number
Specifies the bit number in a word device (0 to 15). This option can only be configured when a word device is selected
for Device Type.
■ Show
Select from the following and display the device addresses on the (Address list).
■ (Toolbar)
■ (Address number list)
Displays a list of device addresses that match the specified condition.
All: Displays all of the device addresses that can be used with the device selected in Target.
Used: Displays only the device addresses that are used in the active project data.
Unused: Displays only the device addresses that are not used in the active project data.
(Cut):
Cuts the selected tag name or comment from (Address number list) and copies it to the
clipboard.
(Copy):
Copies the selected tag name or comment to the clipboard.
(Paste):
Pastes the contents of the clipboard.
(Delete):
Deletes the selected tag name or comment.
(Import):
Shows the Open dialog box.
Select a file with exported tag names and comments (CSV file), and then click Open to
collectively overwrite (Address number list) with the tag names and comments in the
selected file.
(Export):
Displays the Export dialog box.
Select the location to save the file, enter a file name, and then click Save to save the tag
names and comments of (Address number list) as a CSV file.
(Cross Reference):
Shows the Cross Reference dialog box. For details, refer to “Cross Reference Dialog Box” on
page 2-70.
(Refresh):
Updates the Use column on the Tag Editor.
(Add New Tag):
Adds the Allen-Bradley tag data.
This is valid only if the Logix Native Tag(Ethernet) driver of Allen-Bradley is selected
and the external device is selected from the Target. For details, refer to the WindO/I-NV4
External Device Setup Manual.
(Edit Tag):
Edits the registered Allen-Bradley tag data.
This is valid only if the Logix Native Tag(Ethernet) driver of Allen-Bradley is selected
and the external device is selected from the Target. For details, refer to the WindO/I-NV4
External Device Setup Manual.
Device Address: Displays the device addresses of the selected Device Type.
Tag Name: Displays the tag name of the address number.
Comment: Displays the comment of the address number.
Used: Displays how many times each address number has used.
The device addresses of the MICRO/I and external devices are collectively managed in Tag Editor. Tag Editor
can be displayed with the following procedures.
•On the View tab, in the Workspace group, click (Tag Editor).
•Double click Tag Editor in the Project window.
To Next Page
