IDEC MICRO/I HG1P-ST32 Series User Manual

WindO/I-NV4 User’s Manual 18-17
4 Creating and Deleting Data for Recipes
18
Recipe Function
4.2 Creating Recipe Files
Recipe files can be created on the external memory device
*1
with the following procedure. The recipe values
configured on the Data tab in the Individual Settings dialog box are saved in recipe files.
 “Creating Recipe Files in the Recipe Settings Dialog Box” on page 18-17
 “Creating Recipe Files when Downloading Project Data” on page 18-19
 “Creating Recipe Files with a Text Editor” on page 18-20
●
Creating Recipe Files in the Recipe Settings Dialog Box
1 Insert an external memory device in the computer.
To use an SD memory card, insert it into the computer's memory card slot or use it via a memory card reader/writer.
To use a USB flash drive, insert it into the computer's USB port.
2 On the Configuration tab, in the System Setup group, click Recipe.
The Recipe Settings dialog box is displayed.
3 Click Save Recipe Files to External Memory Device.
The Select Drive dialog box is displayed.
*1 SD memory card for HG5G/4G/3G/2G-V, HG4G/3G and HG2G-5F, USB flash drive for HG2G-5T and HG1G/1P
Computer
Through a memory card
reader/writer
SD memory card
SD memory card
In SD memory card slot
In USB port
USB flash drive
