WindO/I-NV4 User’s Manual 21-9
3 Sound Settings Dialog Box
21
Sound Function
■ Trigger Condition
Select None or Device Address for the condition for playing the sound file.
●
Exporting sound files
The sound file can be exported by the steps below.
1 Select and right-click the ID of the sound file to be exported, and click Export Sound Files.
The Browse For Folder dialog box is displayed.
2 Specify a save location and click OK.
None: Select to play the sound file as a touch sound.
Device Address: Play the sound file according to the value of device address.
(Trigger Device Address): Specify the device address that will be the condition for playing
the sound file. Click to display Tag Editor and specify the
device address. For the device address configuration
procedure, refer to Chapter 2 “5.1 Device Address Settings” on
page 2-68.
Repeat: Select this check box to play the sound file repeatedly. The file
will play repeatedly until the Trigger Condition is no longer met.
When this check box is cleared, the file only plays once.
The maximum number of external device addresses that can be used as trigger device addresses is 128.
However, when the bit numbers of a word device are specified, if those bits are in the same word device, it
counts as one device even when multiple bits are used.
The sound file is exported using the current file name.
To Next Page
