WindO/I-NV4 Users Manual 3-13
5 User Communication
3
Communication
10
Select the condition to transmit data in Trigger Type under Trigger Condition from the following.
Rising-edge
Data is transmitted when the value of device address changes from 0 to 1.
Specify the bit device or the bit number of the word device as the condition.
Click to display the Tag Editor. For the device address configuration procedure, refer to Chapter 2 “5.1 Device
Address Settings” on page 2-68.
Falling-edge
Data is transmitted when the value of device address changes from 1 to 0.
Specify the bit device or the bit number of the word device as the condition.
Click to display the Tag Editor. For the device address configuration procedure, refer to Chapter 2 “5.1 Device
Address Settings” on page 2-68.
Satisfy the condition
Data is transmitted when condition changes from not satisfied to satisfied.
Specify the conditional expression in Condition and select the data type handled by the conditional expression in
Data Type.
Click to display the Trigger Condition Settings dialog box. For the conditional expressions configuration
procedure, refer to Chapter 2 “5.2 Setting Conditional Expressions” on page 2-71.
For details on data types, refer to Chapter 2 “1.1 Available Data” on page 2-1.
Fixed Period
Data is transmitted at a fixed time interval.
Set the time interval between data transmissions as 1 to 3600 (seconds) in Period (sec).
11
Specify the bit device or the bit number of the word device for reporting that data transmission was successfully
completed in Completed Device Address under Detail.
Click to display the Tag Editor. For the device address configuration procedure, refer to Chapter 2 “5.1 Device
Address Settings” on page 2-68.
12
Specify the destination word device for the transmitted data size and error information in Status Device Address
under Detail.
Click to display the Tag Editor. For the device address configuration procedure, refer to Chapter 2 “5.1 Device
Address Settings” on page 2-68.
13
Specify the wait time (0 to 255) from when the trigger condition is satisfied to when the data is transmitted in
Transmission Wait (x100 msec) under Detail.
14
Enter a comment for transmission command in Comment under Detail.
The maximum number is 40 characters.
