6 System Information
24-30 WindO/I-NV4 User’s Manual
Displays information about the runtime system and downloaded project data of the MICRO/I.
This function can be used to show information about project data during editing and to simultaneously check details
of project data downloaded to the MICRO/I.
6.1 Displaying System Information
1 Change communication settings according to the connection method between the computer and the MICRO/I.
If communicating with a MICRO/I inserted in a computer, in the Communication Settings dialog box, select MICRO/I
from Communicate with. For details, refer to “1.3 Change Communication Settings” on page 24-5.
2 On the Home tab, in the Project group, click Target Info..
•When Communicate with is set to MICRO/I and Port is set to USB, the System Information dialog box is
displayed.
•When Communicate with is set to MICRO/I and Port is set to Ethernet, the Target IP Address dialog box is
displayed. Specify the IP address of the MICRO/I, and then click OK to display the System Information dialog box.
For details, refer to “To execute any function except project data download” on page 24-10.
6System Information
HG3G
HG2G-5FHG5G-V HG4G-V HG3G-V HG2G-V HG2G-5T
HG4G HG1G HG1P
While editing project data, information about runtime system and project data can be displayed even by
clicking Target Info. in the MICRO/I group on the Online tab.
To Next Page
