IDEC MICRO/I HG1P-ST32 Series User Manual

3 FTP Client Function
28-32 WindO/I-NV4 User’s Manual
Example: The FTP Server Settings are set as follows:
The value of each device address is listed below.
Settings Preset Value
Outgoing FTP Server, IP Address is selected. 192.168.0.44
User Name test_user001
Password test password
Port Number 587
Transfer Mode (0: Pasv, 1: Active) Pasv
Connection Timeout 30
Transfer Ti meout 60
Top Device Address LKR 100
Storage Method of String Data from Upper byte
Settings Preset Value
FTP Server
Device
Address
LKR 100 LKR 101 LKR 102 LKR 103 LKR 104 to LKR 120
Value
(Decimal)
192 168 0 44 Reserved
User Name
Device
Address
LKR 122LKR 123LKR 124LKR 125LKR 126LKR 127LKR 128 LKR 129 to LKR 141
String (ASCII)
‘t’‘e’ ‘s’‘t’ ‘_’‘u’ ‘s’‘e’ ‘r’‘0’ ‘0’‘1’
‘\0’‘\0’
‘
\0’‘\0’
Value
(Hexadecimal)
7465h 7374h 5F75h 7365h 7230h 3031h 0000h 0000h
Password
Device
Address
LKR 142 LKR 143 LKR 144 LKR 145 LKR 146 LKR 147 LKR 148 LKR 149 to LKR162
String (ASCII)
‘t’‘e’ ‘s’ ‘t’ ‘_’‘p’ ‘a’‘s’ ‘s’‘w’ ‘o’‘r’
‘d’‘
\0’ ‘\0’‘\0’
Value
(Hexadecimal)
7465h 7374h 5F70h 6173h 7377h 6F72h 6400h 0000h
Port Number
Device
Address
LKR 163
Value
(Decimal)
587
Trans fer Mode
Device
Address
LKR 164
Value
(Decimal)
0
Connection Timeout
Device
Address
LKR 165
Value
(Decimal)
30
Trans fer Tim eout
Device
Address
LKR 166
Value
(Decimal)
60
LKR 100
LKR 120
LKR 163
LKR 164
LKR 165
LKR 166
LKR 121
LKR 141
LKR 142
LKR 162
(
The address number of Top Device Address) +0
〜
+20
+21
〜
+41
+42
〜
+62
+63
+64
+65
+66
Password
User Name
FTP Server
Port Number
Transfer Mode
Connection Timeout
Transfer Timeout
