WindO/I-NV4 User’s Manual 28-33
3 FTP Client Function
28
Maintenance
3.7 File Transfer Settings Dialog Box
This section describes the items and buttons on the File Transfer Settings dialog box.
●
File Transfer Settings Dialog Box
Use the File Transfer Settings dialog box to collectively manage the trigger condition for copying or moving files
between the FTP server and an external memory device inserted in the MICRO/I.
■ (Settings)
Displays a list of the settings of the File Transfer function. Double clicking the cell displays the Individual Settings
dialog box where you can edit the settings. For details, refer to “Individual Settings Dialog Box” on page 28-34.
■ Edit
Registers or changes the settings for the selected number.
Select a number from the (Settings) and click this button to display the Individual Settings dialog box. The
configured content for the selected number is reflected in the Individual Settings dialog box.
For details, refer to “Individual Settings Dialog Box” on page 28-34.
■ Delete
Deletes the settings for the selected number from the (Settings).
■ Up
Shifts the selected settings upward in the list.
■ Down
Shifts the selected settings downward in the list.
No.: Displays the number for managing File Transfer Settings.
Source: Displays the source external memory device or the FTP server where the files to be copied or
moved are stored.
Destination: Displays the target external memory device or the FTP server where the files to be copied or
moved are stored.
Trigger Type: Displays the trigger type for copying or moving files.
Trigger Condition: Displays the trigger condition of trigger type for copying or moving files. The displayed content
varies based on Trigger Type.
Rising-edge, Falling-edge: Displays the bit device or the bit number of the word device to
serve as condition.
Satisfy the condition: Displays the conditional expression.
To Next Page
