WindO/I-NV4 User’s Manual 29-19
2 PLC Program Transfer Function
29
Data Transfer Function
2.5 Using Key Buttons, Multi-Buttons, or Multi-Commands to Transfer PLC Programs
● Download
1 Convert a PLC program file for PLC program transfer.
For details, refer to “2.4 Creating ZLD Project File” on page 29-18.
2 Save it to an external memory device
*1
.
3 Insert an external memory device
*1
in the MICRO/I.
4 Press the Key Button or Multi-Button or execute the Multi-Command configured with Download PLC Program
under Data Transfer on the Key Browser dialog box.
*1 Only USB flash drive for HG2G-5T and HG1G/1P
Allocate a Key Button, Multi-Button, or Multi-Command configured with the PLC program transfer function to
the MICRO/I.
 For details, refer to Chapter 8 “5 Key Button” on page 8-72.
 For details, refer to Chapter 8 “6 Multi-Button” on page 8-108.
 For details, refer to Chapter 12 “6 Multi-Command” on page 12-38.
Save
Computer
ZLD Project File
(.zld)
USB flash drive
SD memory card
External Memory Device
PLC
MICRO/I
USB flash drive
SD memory card
External Memory Device
