1 Overview
30-4 WindO/I-NV4 Users Manual
Checking the Hardware Version Number
The analog I/O module hardware version number is printed on the side of the analog I/O module. The performance
and functionality of the analog I/O module will differ by its version, so check the version number before use.
Restrictions when connecting the expansion modules
The expansion module for FC4A and the expansion module for FC6A cannot be used together.
Always turn the MICRO/I and the expansion module off before attaching or detaching an expansion module.
Use the expansion module clamp (sold separately) when using expansion modules.
Order the module clamp by referring to the width of the module shown in the dimensions of each module.
When connecting more than 2 expansion modules, note the limits shown below.
S/N:XXXXX-XXXXX V100
Version Number
Type No.
Quantity of
Applicable Analog
I/O Modules
Total width when
connecting more
than 2 expansion
modules
Current flow rate
at 5V
Current flow rate
at 24V
HG5G-V 4 93.0 mm max. 130 mA max. 50 mA max.
HG4G/3G-V, HG4G/3G 2 93.0 mm max. 130 mA max. 150 mA max.
HG2G-V, HG2G-5F 2 70.0 mm max. 130 mA max. 150 mA max.
HG3G
HG2G-5F HG2G-5T
HG4G HG1G
HG3G
HG2G-5FHG5G-V HG4G-V HG3G-V HG2G-V HG2G-5T
HG4G HG1G HG1P
