WindO/I-NV4 Users Manual 30-5
1 Overview
30
Expansion Modules
Expansion Module Slot Information
Expansion module type information is written to HMI Special Data Registers (LSD270 to 277). The details are shown
below.
Status
Type ID
System Software Version
Displays the version of the system software written to the device.
Upper Lower Description
LSD270 LSD271 Expansion Module Slot 1 Information
LSD272 LSD273 Expansion Module Slot 2 Information
LSD274 LSD275 Expansion Module Slot 3 Information
LSD276 LSD277 Expansion Module Slot 4 Information
HG3G
HG2G-5F HG2G-5T
HG4G HG1G
HG3G
HG2G-5FHG5G-V HG4G-V HG3G-V HG2G-V HG2G-5T
HG4G HG1G HG1P
Status Type IDUpper
Position Information System Software VersionLower
Slot Number (1 to 4)
Bit
15
Bit
0
Bit
7
Bit
8
12
34
5
6
910
1112
13
14
Status
Description
Hexadecimal Binary
0x00 0000 0000 Normal
0x81 1000 0001
Communication error (An error has occurred in the communication between MICRO/I and
an expansion module.)
0x82 1000 0010 Unknown device detected
0x83 1000 0011
Device setting error (No device is connected or the connected device is different from that
set in the project.)
0x84 1000 0100 Device writing error (The attempt to set the operation of the device failed.)
Type ID
Type No.
Hexadecimal Binary
0x00 0000 0000 FC6A-N16B1, FC6A-N16B3
0x01 0000 0001 FC6A-R161, FC6A-T16K1, FC6A-T16P1, FC6A-T16K3, FC6A-T16P3
0x02 0000 0010 FC6A-N32B3
0x03 0000 0011 FC6A-T32K3, FC6A-T32P3
0x04 0000 0100 FC6A-N08B1, FC6A-N08A11
0x05 0000 0101 FC6A-R081, FC6A-T08K1, FC6A-T08P1
0x06 0000 0110 FC6A-M08BR1
0x07 0000 0111 FC6A-M24BR1
0x20 0010 0000 FC6A-J2C1
0x21 0010 0001 FC6A-J4A1
0x22 0010 0010 FC6A-J8A1
0x23 0010 0011 FC6A-K2A1
0x24 0010 0100 FC6A-K4A1
0x25 0010 0101 FC6A-L06A1
0x26 0010 0110 FC6A-L03CN1
0x27 0010 0111 FC6A-J4CN1
0x28 0010 1000 FC6A-J8CU1
0x2B 0010 1011 FC6A-J4CH1Y
