IDEC MICRO/I HG1P-ST32 Series User Manual

3 Analog I/O Modules
30-22 WindO/I-NV4 User’s Manual
■ Data Type
The analog output value can be handled as the set data type. There are two data types for the analog outputs.
YES: Supported, NO: Not supported
■ Minimum and Maximum values
The value written to the data register is output from the analog output. The minimum and maximum values that can
be written are determined by the set signal type and data type. A parameter setting error occurs when a value is set
that exceeds the minimum or maximum value.
The minimum and maximum values that correspond to the signal types and data types are as follows.
■ Data
The analog output data for the analog output set with the Signal Type, the Data Type, the Min. and the Max. is
stored in the data registers in the END progressing of each scan. The actual analog output data is not guaranteed
when the analog output Status is a value other than "0".
■ Status
The status of the analog output Data is stored in data registers.
*1 The minimum and maximum values can be set only when the data type is set to optional range. Set the minimum and
maximum values between -32,768 and 32,767.
Data Type FC6A-K2A1 FC6A-K4A1 FC6A-L06A1 FC6A-L03CN1
Binary data YESYESYESYES
Optional range YES YES YES YES
Signal Type
Data Type
Binary Data
Optional Range
*1
0 to 10 V 0 to 4,095 -32,768 to 32,767
-10 to +10 V -2,048 to 2,047 -32,768 to 32,767
0 to 20 mA 0 to 4,095 -32,768 to 32,767
4 to 20 mA 0 to 4,095 -32,768 to 32,767
Status Description
0 Operating normally
1Reserved
2Initializing
3 Parameter setting error
4 Hardware fault (external power supply error)
5 to 65,535 Reserved
