WindO/I-NV4 User’s Manual 31-7
1 External Memory Devices
31
External Memory Devices
Uploading
This procedure shows how to upload specified data from the External Memory Device folder on the external memory
device for the currently running project.
1 On the Home tab, in the Project group, click the arrow next to Upload.
2 Click Stored Data in External Memory Device.
The Upload Data from External Memory Device dialog box appears.
3 Select the items to be uploaded, and then specify the destination folder in the Location box.
Uploadable data is as follows.
• Screenshots
•Alarm Log Files
• Data Log Files
•Operation Log Files
• Recipe Files
•Picture Files
• Sound Files
*1
• Movie File List
*2
• Movie Files
*2
4 Click OK.
The External Memory Device Maintenance dialog box appears and the data upload begins.
A message box appears when the data upload is complete.
*1 This is applicable for models with an audio interface only.
*2 This is applicable for models with a video interface only.
If security is enabled for the project on MICRO/I, a dialog appears for you to enter a user name and
password. For details, refer to Chapter 23 “User Accounts and the Security Function” on page 23-1.
• Click to call up the Select a Folder dialog box and specify the destination folder for uploading.
• After starting WindO/I-NV4, screen shots, alarm log data, data log data, and recipe files can be uploaded
from an External Memory Device folder without opening project data.
To Next Page
