WindO/I-NV4 User’s Manual 31-15
1 External Memory Devices
31
External Memory Devices
1.6 Setting the External Memory Device Folder
The External Memory Device folder
*1
on the external memory device can be renamed using WindO/I-NV4.
1 On the Configuration tab, in the System Setup group, click Project.
The Project Settings dialog box appears.
2 On the External Memory Device tab, enter the desired name in the External Memory Device Folder text box.
Use only alphabetic characters (A to Z) and numbers (0 to 9) and the maximum is 8 characters.
3 Click OK.
*1 SD memory card for HG5G/4G/3G/2G-V, HG4G/3G and HG2G-5F, USB flash drive for HG2G-5T and HG1G/1P
It is not possible to change folder names and file names other than the External Memory Device folder.
The External Memory Device folder is named “HGDATA01” if project data has never been downloaded to the
MICRO/I.
To Next Page
