2 Word Devices
33-8 WindO/I-NV4 User’s Manual
*5 HG2G-5T, HG1G/1P only
*6 HG5G/4G/3G/2G-V, HG4G/3G, HG2G-5F only
Device Address Function/Part
LSD34 USB flash drive free memory capacity Lower word (Kbytes)
LSD35 USB flash drive free memory capacity Upper word (Kbytes)
LSD36 USB flash drive total memory capacity Lower word (Kbytes)
LSD37 USB flash drive total memory capacity Upper word (Kbytes)
LSD38
*6
Execution time of the Cyclic Script (Current value) (msec.)
LSD39
*6
Execution time of the Cyclic Script (Maximum value) (msec.)
LSD40
*6
Execution time of the Cyclic Script (Minimum value) (msec.)
LSD41 Reserved
LSD42
*6
SD memory card error status
0: Normal
1: A write occurred when the USB flash drive was not inserted or when an incompatible USB flash
drive was inserted
2: Format error
3: Access error, Insufficient memory in Memory card or Reading or writing failure.
4: Unsuccessful read of picture data
LSD43
*6
SD memory card free memory capacity Lower word (Kbytes)
LSD44
*6
SD memory card free memory capacity Upper word (Kbytes)
LSD45
*6
SD memory card total memory capacity Lower word (Kbytes)
LSD46
*6
SD memory card total memory capacity Upper word (Kbytes)
LSD47 Reserved (for Communication drivers)
LSD48 Reserved
LSD49 Stores the O/I Link slave station number. (Read-only)
LSD50
The sequence value of the message number (or channel number if the alarm function is being
used) selected by the cursor in the Alarm List Display is stored.
A value of between 1 and 1024 (allocated using ((Block No. - 1) x 16 + bit position + 1)) is stored
for the number.
LSD51
Brightness level: -16 to 31
*6
, 0 to 31
*5
LSD52 The ID number of the script for which the error occurred.
LSD53 Script error status
LSD54 Reserved (for Script)
LSD55 Reserved
LSD56
The number of lines of data from the start line to the line currently selected with the cursor
displayed in the Alarm List Display/Alarm Log Display is stored.
LSD57
The number of log data pieces stored in the Data Storage Area by the alarm log function is stored.
(0 to 1024)
LSD58
*5
USB flash drive download status
The following bit becomes to 1 while downloading to USB flash drive by WindO/I-NV4.
The bit switched to 0 after downloading.
Bit 2: Recipe file
Bit 4: ZNV Project File
Bit 5: Picture file
Bit 9: ZLD Project File
