MICRO/I Specifications
■ HG4G-V (12.1inch)
Unit: mm
# The size to the expansion module installation side
<Cable Attached Dimensions>
Depending on the type of connection cable used the dimensions shown above will change.
The dimensions given here are representative values and are intended for reference only.
11.4
44.4
227.0
6.0 48.1
54.1
＃
32.3
314.0
240.0
301.0
227.0
301.010
50
30
55
