IDEC MICRO/I HG1P-ST32 Series User Manual

1 HG5G/4G/3G/2G-V
35-8 WindO/I-NV4 User’s Manual
1.6 Dimensions
■ HG5G-V (15.0inch)
Unit: mm
# The size to the expansion module installation side
<Cable Attached Dimensions>
Depending on the type of connection cable used the dimensions shown above will change.
The dimensions given here are representative values and are intended for reference only.
＃
33.0
6.0 48.8
54.8
351.5
278.5
69.5
11.4
291.5
364.5
278.5
351.5
50
30
55
