MICRO/I Specifications
â– Performance Specifications
â– EMC Specifications
*1 Please be aware that small black and bright dots might show up on LCD Screen: it is not a failure or malfunction.
*2 The time until brightness becomes 50% of the initial value.
The life of the LCD itself at an ambient temperature of 25°C. This is not a guaranteed value. The actual life depends on the
environment and conditions of use.
*3 It is a protection structure for the operating surface of HMI, which is attached to a panel. Although protection structure
suffices every test conditions, it does not guarantee to operate under all of the environmental condition.
As for IP66F/IP67F oilproof structure, it suffices oilproof test conditions. Conditions are listed in the document that comes
with Japanese Industrial Standard JIS C 0920.
Protection structure do not gurantee usage under long exposure to oil or usage of oil that is not prescribed in the document.
Please test/check beforehand to avoid trouble.
Type No. HG5G-V HG4G-V HG3G-VA HG3G-V8 HG2G-V
Display
LCD Type
*1
TFT color LCD
(TN Type)
TFT color LCD (IPS Type)
TFT color LCD
(TN Type)
Display Colors 65536 Colors
Effective Display Area
(W × H)
304.1 × 228.1 mm
245.76 ×
184.32 mm
210.4 × 157.8
mm
170.496 ×
127.872 mm
115.2 × 86.4
mm
Display Resolution
(W × H)
1024 × 768 dots 640 × 480 dots
View angle
Left/Right/Bottom:
80°, Top: 60°
Left/Right/Top/Bottom: 85°
Left/Right/Top/
Bottom: 80°
Brightness of LCD only
650 cd/m
2
600 cd/m
2
700 cd/m
2
800 cd/m
2
800 cd/m
2
Brightness Adjustment 48 levels
Backlight LED
Backlight Life
*2
Approx. 100,000 hours
Touch
Panel
Switch Type Analog Resistive Film
Operating Force 3N maximum
Multiple Operations Impossible
Life 1,000,000 operations
User Memory Approx. 58 MB
Backup Battery
Coin type lithium manganese dioxide battery CR2032W
Guarantee Period: 1 Year (Operating Temperature at 25°C)
Recommended Replacement Span: Every 5 Years (Operating Temperature at 25°C)
Backup Data Calendar, Log Data, HMI Keep Relays, HMI Keep Registers
Buzzer output Single tone (tone length is adjustable)
Degree of Protection
*3
IP66, IP67 (IEC60529)
TYPE 4X
Weight (approx.) 3.2kg 2.1kg 1.65 kg 1.25 kg 0.65 kg
Radiated Emission
Class A : 10m
40dBµV/m quasi-peak (30M to 230MHz)
47dBµV/m quasi-peak (230M to 1GHz)
Electrostatic Discharge Contact : ±6kV Air : ±8kV
Electromagnetic Field
10V/m (80 to 1000 MHz)
3V/m (1.4 to 2.0 GHz)
1V/m (2.0 to 2.7 GHz)
80% AM (1kHz)
Fast Transient Burst Power : ±2kV Communication cable : ±1kV
Surge Immunity ±500V (between +24V and 0V) ±1kV (between +24V and FE, 0 and FE)
Conducted Radio
Frequency Immunity
3V (Power, Communication cable) (150kHz to 80MHz)
80% AM (1kHz)
