1 HG5G/4G/3G/2G-V
35-6 WindO/I-NV4 User’s Manual
1.5 Specifications
■ Applicable Standards
■ Environmental Specifications
■ Electrical Specifications
■ Construction Specifications
Safety Standard
UL61010-1, UL61010-2-201, UL121201
CSA C22.2 No.61010-1-12 (c-UL)
CSA C22.2 No.61010-2-201 (c-UL)
CSA C22.2 No.213 (c-UL)
EMC Standard IEC/EN 61131-2
Operating Temperature -20 to 60°C
Operating Humidity 10 to 90% RH (no condensation)
Storage Temperature -20 to +70°C
Storage Humidity 10 to 90% RH (no condensation)
Altitude 0 to 2000m
Pollution Degree 2
Corrosion Immunity Free from corrosive gases
Type No. HG5G-V HG4G-V HG3G-VA HG3G-V8 HG2G-V
Rated Voltage 24V DC
Power Consumption 27W maximum 25W maximum 22W maximum 18W maximum
When not using USB Interface
(USB2) and Expansion Module
Interface (EXT)
20W maximum 15W maximum 12W maximum 8W maximum
When backlight is turned off 7W maximum 4W maximum
Power Voltage Range 20.4 to 28.8V DC
Allowable Momentary Power
Interruption
10 ms maximum
Inrush Current 30A maximum
Dielectric Withstand Voltage AC1000V, 10mA, 1 minute (between power and earth terminals)
Vibration
5 to 8.4Hz amplitude 3.5mm, 8.4 to 150Hz acceleration 9.8m/s
2
10 times on each of three mutually perpendicular axes (100 minutes) (IEC61131-2)
Shock
147m/s
2
, 11ms (5 shocks on each of three mutually perpendicular axes)
(IEC61131-2)
