4.5 Specifications
■ Applicable Standards
■ Environmental Specifications
■ Electrical Specifications
■ Construction Specifications
CAUTION
The following specifications are when the HG1P optional cable, specified by IDEC, is attached.
Safety Standards
UL61010-1
UL61010-2-201
CSA C22.2 No.61010-1 (c-UL)
CSA C22.2 No.61010-2-201 (c-UL)
EMC Standards
IEC/EN 61131-2
FCC
Operating Temperature 0 to +45°C
Operating Humidity 10 to 90% RH (no condensation)
Storage Temperature -10 to +60°C
Storage Humidity 10 to 90% RH (no condensation)
Altitude and Atmospheric Pressure
Up to 2000m (RUN)
750 to 1060hPa
Pollution Degree 2
Corrosion Immunity Free from corrosive gases
Rated Voltage 24V DC
Power Consumption
3W maximum
When not using USB Interface (USB2): 2W maximum
Power Voltage Range 20.4 to 28.8V DC
Allowable Momentary Power
Interruption
10 ms maximum
Inrush Current 20A maximum
Dielectric Withstand Voltage AC500V, 10mA, 1 minute (between power and ground terminals)
Vibration
5 to 8.4Hz amplitude 3.5mm,
8.4 to 150Hz acceleration 9.8m/s
2
1 octave 10 minutes
10 times on each of three mutually perpendicular axes (100 minutes)
(IEC61131-2)
Shock
147m/s
2
, 11ms (5 shocks on each of three mutually perpendicular axes)
(IEC61131-2)
Dropping 1.5 m, 6 directions, 1 time
Connector Insertion Life
HG1P Optional Cable: 100 times
USB1: 5000 times
USB2: 1500 times

IDEC MICRO/I HG1P-ST32 Series Specifications

General

Brand	IDEC
Model	MICRO/I HG1P-ST32 Series
Category	Control Panel
Language	English
