WindO/I-NV4 User’s Manual 35-61
4 HG1P
35
MICRO/I Specifications
â– Performance Specifications
â– Communication Specifications
*1 The time until brightness becomes 50% of the initial value.
The life of the LCD is specified an ambient temperature of 25°C. This is not a guaranteed value. The actual life depends on
the environment and conditions of use.
*2 The HG1P has no backup battery, therefore, time data is deleted when the HG1P is turned off.
*3 The connector for the external device is not guaranteed.
Display
LCD Type TFT color LCD
Display Colors 65536 Colors
Effective Display
Area
95.04 (W) × 53.856 (H) mm
Display Resolution 480 (W) × 272 (H) dots
View angle Left/Right: 80°, Top: 65°, Bottom: 55°
Brightness of LCD
only
400 cd/m
2
Brightness
Adjustment
32 levels
Backlight White LED (It cannot be replaced)
Backlight Life
*1
Approx. 30,000 hours
Touch Panel
Switch Type Analog Resistive Film
Operating Force 3N maximum
Multiple Operations Impossible
Life 1,000,000 operations
User Memory 12MB
Clock Function
*2
Year, Month, Day, Hour, Minute, Second, Day-of-week
±90 seconds per month
Buzzer output Single tone (tone length is adjustable)
Degree of Protection
IP54 (When HG1P optional cable is attached
*3
)
Weight Approx. 500g (without HG1P optional cable)
Housing color Dark gray
Serial Interface (RS422/485)
Communication Speed
187500, 115200, 57600, 38400, 19200, 9600, 4800,
2400, 1200 bps
Communication Distance 20m maximum
Synchronization Asynchronous
Ethernet Interface
Interface Specification IEEE802.3i
Baud Rate 10M
To Next Page
