IDEC MICRO/I HG1P-ST32 Series User Manual

4 HG1P
35-62 WindO/I-NV4 User’s Manual
■ EMC Specifications
Radiated Emission
Class A : 10m
•IEC 61000-6-4 Class A
40dBμV/m quasi-peak (30M to 230MHz)
47dBμV/m quasi-peak (230M to 1GHz)
•FCC Class A
39dBμV/m quasi-peak (30M to 88MHz)
43.5dBμV/m quasi-peak (88M to 216MHz)
46.4dBμV/m quasi-peak (216M to 960MHz)
49.5dBμV/m quasi-peak (960M to 1GHz)
Electrostatic Discharge
Contact : ±4kV
Air : ±8kV
Electromagnetic Field
10V/m (80 to 1000 MHz)
3V/m (1.4 to 2.0 GHz)
1V/m (2.0 to 2.7 GHz)
80% AM (1kHz)
Fast Transient Burst
Power : ±2kV
Communication cable : ±1kV
Surge Immunity
±500V (+24V and 0V)
±1kV (+24V and FE, 0V and FE)
Conducted Radio
Frequency Immunity
3V (Power, Communication cable)
(150kHz to 80MHz)
80% AM (1kHz)
