5 User Communication
3-72 WindO/I-NV4 User’s Manual
Example: Registering Constant (Hexadecimal) for receive command data
When the trigger condition is satisfied, the received data is compared with the registered hexadecimal data, and the
value of the Index No. 2 of the matching data is stored in Index Device Address LDR100.
When the LDR100 value is 3
Example of applying Registering Constant
When the same device address is specified for the Index Device Address for Registering Constant (Character)
data or Registering Constant (Hexadecimal) data and for Use Reference Device Address for Device
Address data, the data storage destination for each unit of received data can be changed.
When the following commands are received
• The first 1 byte is taken as the start code. Constant (Hexadecimal) data is not stored.
• The received data is compared with the registered data, and the value of the Index No. 2 (Dec) of the matching
data is stored in Index Device Address LDR100.
Item Setting
Number of Registering Constants 3
Registering Constants
Index No. 1: 1234
Index No. 2: 5678
Index No. 3: 2537
Index Device Address LDR100
Received data
Compare
25h
37h
Order of reception
3LDR100:
Value of the Index Device Address
1234h
5678h
2537h
1:
2:
3:
DataIndex No.
Number of
Registering
Constants: 3
(DEC)
Data type Item Setting
Constant (Hexadecimal) Data 02
Registering Constant (Character)
Number of Registering Constants 2
Registering Constant
Index No. 1: AA
Index No. 2: BB
Index Device Address LDR100
Device Address
Conversion Type No conversion
Device Address LDR100
Use Reference Device Address ON, Device Address: LDR200
Storage Method for Data from Upper byte
Bytes 2
Words 2
Variable OFF
Constant (Hexadecimal) Data 0D
STX
(02h)
B
(42h)
B
(42h)
1
(31h)
2
(32h)
CR
(0Dh)
STX
(02h)
Received data
Compare
B
(42h)
B
(42h)
Order of reception
2LDR100:
Value of the Index Device Address
AA
BB
1:
2:
DataIndex No.
Number of
Registering
Constants: 2
(DEC)
To Next Page
