WindO/I-NV4 User’s Manual 4-39
3 Project Settings Dialog Box
4
Project Settings
When SERIAL1(RS232C), SERIAL1(RS422/485), COM(RS232C), or COM(RS422/485) is selected under
Interface Configuration
The items displayed in the Interface vary based on the model.
*1 HG1G only
HG2G-5T: SERIAL1(RS232C), SERIAL1(RS422/485)
HG1G/1P:
COM(RS232C)
*1
, COM(RS422/485)
Function: Selects the function used by Serial Interface from the following.
N/A, External Device Communication 1, External Device Communication 2, External
Device Communication 3, External Device Communication 4, O/I Link Master, O/I Link
Slave, User Communication 1, User Communication 2, User Communication 3, Sub Host
Communication
This communication interface is not used when N/A is selected.
The O/I Link Master and the O/I Link Slave can only be configured when the
SERIAL1(RS422/485) or the COM(RS422/485) is selected for the Interface under the
Interface Configuration.
Baud Rate: Selects the communication speed with the external device from the following.
1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200, 187500
The baud rate that can be configured varies based on Protocol.
Data Bits: Selects the data length as 7 or 8.
This option can only be configured when External Device Communication 1, External Device
Communication 2, External Device Communication 3, External Device Communication
4, User Communication 1, User Communication 2, User Communication 3, or Sub Host
Communication is selected for Function.
Stop Bits: Selects the stop bits as 1 or 2.
This option can only be configured when External Device Communication 1, External Device
Communication 2, External Device Communication 3, External Device Communication
4, User Communication 1, User Communication 2, User Communication 3, or Sub Host
Communication is selected for
Function.
P
arity: Selects the parity from the following.
None, Odd, Even
This option can only be configured when External Device Communication 1, External Device
Communication 2, External Device Communication 3, External Device Communication
4, User Communication 1, User Communication 2, User Communication 3, or Sub Host
Communication is selected for Function.
Flow Control: Selects the flow control method as None or ER according to the external device being used.
This option can only be configured when External Device Communication 1, External Device
Communication 2, External Device Communication 3, External Device Communication
4, or Sub Host Communication is selected for Function.
Serial Interface: Select the interface standard for the serial port. The items that can be displayed vary based on the
Interface under the Interface Configuration.
SERIAL1(RS232C), COM(RS232C)
*1
:
RS232C
SERIAL1(RS422/485), COM(RS422/485): RS422/485 2-wire, RS422/485 4-wire
This option can only be configured when External Device Communication 1, External Device
Communication 2, External Device Communication 3, External Device Communication
4, User Communication 1, User Communication 2, User Communication 3, or Sub Host
Communication is selected for Function.
