3 Project Settings Dialog Box
4-48 WindO/I-NV4 User’s Manual
Communication drivers that cannot be simultaneously used
The following communication driver combinations can only be used in a single (Function). They cannot be configured
in multiple settings.
■ Communication drivers that cannot be simultaneously used (1)
■ Communication drivers that cannot be simultaneously used (2)
*1
■ Communication drivers that cannot be simultaneously used (3)
Example: Communication Driver for External Device Communication 1 is set to Modbus RTU Slave
According to the communication drivers that cannot be simultaneously used (1), External Device
Communication 2, External Device Communication 3, and External Device Communication 4
cannot be set to Modbus RTU Master, S7-200(PPI), S7-MPI, or MP920-RTU.
According to the communication drivers that cannot be simultaneously used (3), External Device
Communication 2, External Device Communication 3, and External Device Communication 4
cannot be set to DM Link (1:1), DM Link (1:N), DM Link Ethernet(UDP)
*1
, or Modbus TCP Server.
*1 HG5G/4G/3G/2G-V, HG4G/3G, HG2G-5F only
Manufacturer Communication Driver
Modbus
Modbus RTU Master
Modbus RTU Slave
SIEMENS
S7-200(PPI)
S7-MPI
YASKAWA ELECTRIC CORPORATION MP920-RTU
Manufacturer Communication Driver
Allen-Bradley
Logix Controllers(Ethernet)
Logix Native Tag(Ethernet)
Manufacturer Communication Driver
IDEC System
DM Link (1:1)
DM Link (1:N)
DM Link Ethernet(UDP)
*1
Modbus
Modbus RTU Slave
Modbus TCP Server
