WindO/I-NV4 Users Manual 5-21
4 Popup Screen
5
Screen
Title
Enter the Popup Screen’s title. Maximum number is 40 characters. This title is displayed in the Popup Screen’s title bar.
This option can only be entered when Use Text Manager is cleared.
Size
Screen List
This list shows screens that have already been created. It is only displayed when creating a new screen.
Options Tab
Background Color
Select the screen’s background color (color: 256 colors, monochrome: 16 shades). Click this button to open the color
palette. Select the color with the color palette.
Screen Effects
Title Bar
Select this to display the title bar on the Popup Screen. The text set in Title on the General tab is displayed in the
title bar.
The title bar is not displayed if superimpose is set.
Width, Height: Specify the width (40 dots to Base Screen width) and the height (40 dots to Base Screen height) of
the Popup Screen.
None: Displays the Popup Screen’s background with the color specified in Background Color.
Transparency: Displays the Popup Screen’s background as transparent. The amount of transparency can be selected
from 10% to 90% in 10% increments.
Superimpose: Displays the Popup Screen’s background as completely transparent. The screen underneath the
Popup Screen can be seen.
If you select Superimpose, the buttons underneath the Popup Screen set to superimpose are active.
If Superimpose is selected in Screen Effects, magenta (R:255, G:4, B:255) is treated as the transparent
color. If you place pictures on a Popup Screen set to superimpose that use this color, those areas are
completely transparent.
Move Button:
Select this to display the (Move) button on the title bar.
Close Button:
Select this to display the (Close) button on the title bar.
